Technical

Transmitter-TX

Receiver-RX

HDMI compliance

HDMI2.0

HDCP compliance

HDCP2.2

Transmission meduim

HDBaseT

Transmission distance

CAT5E/CAT6/CAT6A/CAT7

Video bandwidth

CAT6： 1080p@60Hz 36bpp   up to 70 meters
              1080p@60Hz 48bpp&3D ， 4K×2K@30Hz/60Hz    up to 40 meters
CAT5E：1080p@60Hz 36bpp up to 60 meters
               1080p@60Hz 48bpp&3D ， 4K×2K@30Hz/60Hz  up to 35 meters

Video support

480i@60Hz、480p@60Hz、576i@50Hz、576p@50Hz、
720p@50/60Hz、1080i@50/60Hz、1080p@50/60Hz
4K×2K@24/25/30/60Hz

Audio support

LPCM, DTS-HD, Dolby Ture HD

InputTMDS signal

0.7~1.2Vp-p

InputDDC signal

5Vp-p

CEC

Supported

RS232 support

no

POH support

Supported,  recommended to connnect the power adapter to the RX unit

latency

zero latency

supported configuration

point to point  connection

IR passback

yes, bi-direction

IR frequency

20-60KHz

Input

HDMI×1， 3.5mm jack(IR)×1， DC2.1×1

DC2.1,  RJ45×1， 3.5mm jack(IR)×1

Output

RJ45×1， 3.5mm jack(IR)×1

HDMI×1， 3.5mm jack(IR)×1

HDMI source control

Controllable via IR passback from RX to TX

HDMI conector

Type A 19 Pins,Female

Network cable standard

CAT5E/CAT6/CAT6A/CAT7 ,  follow IEEE-   5688 standard

Mechanical

Transmitter-TX

Receiver-RX

Housing

Metal enclosure

Dimensions(L×W×H mm)

98.5×66.5×23mm
