Dimensions - Cut-Out Diameter

15.24cm

Dimensions - Mounting Depth (includes 1/2 drywall)"

22.54cm

Dimensions - Overall Depth

23.81cm

Dimensions - Overall Diameter

19.68cm

Dimensions - Pre-Construction Bracket

Driver Complement Midrange - Diameter

2 1/2 "

Driver Complement Midrange - Quantity

1

Driver Complement Midrange - Type

Dynamic Balance driver with aerated polypropylene cone

Driver Complement Subwoofer - Diameter

5 "

Driver Complement Subwoofer - Quantity

1

Driver Complement Subwoofer - Type

Dynamic Balance woofer with mineral-filled polypropylene cone

Driver Complement Tweeter - Diameter

3/4 "

Driver Complement Tweeter - Quantity

1

Driver Complement Tweeter - Type

Ring radiator

Electrical - Efficiency

89 dB

Electrical - Inputs

Gold-plated spring-loaded posts

Electrical - Lower -3dB Limit

48 Hz

Electrical - Nominal Impedance

8 ohms

Electrical - Recommended Amplifier Power

10-125 watts per channel

Electrical - Total Frequency Response

35Hz-33kHz

Electrical - Upper -3dB Limit

29 kHz
