PERFORMANCE

Recommended amplifier power

20 -170 Watts

Continuous power handling

85 Watts RMS

Peak power handling

340 watt

Sensitivity

91dB (2.83 Volts @1 metre)

Nominal impedance

8 Ohms

Minimum Impedance

5 ohm

Frequency Response

39 Hz - 46 kHz (-6 dB)

Dispersion

90 degrees conical

DRIVE UNITS

Dual Concentric™ high frequency

25mm (1.00”) aluminium/magnesium alloy dome with edge wound voice coil

Dual Concentric™ low frequency

254mm (10.00") with paper pulp cone with twin roll impregnated fabric surround. 42mm (15/8") edge wound voice coil

CROSSOVER

Frequency

1.8kHz

Type

Bi-wired, hard wired passive, low loss 2nd order low pass, 2nd order high pass

Adjustment

/- 3dB over 1.8 kHz to 46 kHz shelving

CONSTRUCTION

Enclosure type

Dual Distributed Port

Volume

85L (3 cu.ft)

Dimensions

850 x 397 x 368mm
(33.50 x 15.50 x 14.50”)

Finish

Walnut veneer with solid walnut trim and edging. Internally cross braced and heavily damped.
