Power output120 watts RMS per channel, 6 ohms (two channels driven), 155 watts RMS per channel, 4 ohms (two channels driven), 100 watts RMS per channel, 8 ohms (two channels driven), 60 watts RMS per channel, 8 ohms (all 7 channels driven)

HDMI HDMI 2.0, HDCP 2.2, ARC supported on HDMI 1 output

Audio Inputs3 x Analogue, Tuner (FM/AM), 7.1 multi-channel analogue direct, 2 x digital coaxial, 2 x optical

Video Inputs 6 x HDMI 2.0, 1 x MHL compatible (HDMI 1.4 - max 1080p)

Main Audio Outputs7 Amplified Speaker Outputs, 2 x subwoofer outputs

Video Output2 x HDMI 2.0, ARC through HDMI 1

Other connections1 x 1/4” / 6.35mm Headphone Output (32 To 600 ohms recommended), IR emitter input, IR receiver input, 2x IR outputs2 x 12V trigger outputs, 1 RS232C, 1 IEC type mains inlet, Wi-Fi module, RJ45 Ethernet, BT100 Bluetooth (BT100 not supplied), Spotify Connect

Audio formats (network streaming and USB HDD)ALAC, WAV, FLAC, AIFF, WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis (16-24 bit, 11.025-192kHz), DSD (via HDMI)

Max power consumption1000W

Standby power consumption<0.5W

Dimensions (H x W x D)*165 x 430 x 420mm

Weight13.2kg
